DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier
Call for Price
● Built-in 500W digital amplifier, integrated Dante technology
● 8 zones speaker oupput with individual management
● Auto detection for system failure, AC/DC, paging Mic, etc.
● Zones extendable by another extender amplifier
● Support remote control via computer
● Comply with EN54-16 requirements
Description
DSPPA PAVA8500E 8 Zones Integrated Voice Alarm PA System Extender Amplifier in Bangladesh
Built-in 500W digital amplifier, integrated Dante technology, 8 zones speaker output with individual management Auto-detection for system failure, AC/DC, paging Mic, etc. Zones extendable by another extender amplifier Support remote control via computer Comply with EN54-16 requirements.
DSPPA PAVA8500E in Bangladesh :
| Model | PAVA8500 | PAVA8500E | |||
| Rated output power | ≥500W（100V） | ||||
| Input sensitivity | Emergency mic | 5mV 600Ω | —— | ||
| Line | 1000mV 10kΩ | ||||
| Harmonic distortion | Emergency mic | <1% 1kHz | —— | ||
| Line | <1% 1kHz | ||||
| Freq. response | Emergency mic | 80Hz-15kHz（±3dB） | —— | ||
| Line | 50Hz-18kHz（±3dB） | ||||
| Signal to noise ratio | Emergency mic | >75dB（A weighting） | —— | ||
| Line | >80dB（A weighting） | ||||
| Line output | Output voltage | 1000mV | —— | ||
| Frequency range | 80Hz-15kHz（±3dB） | —— | |||
| Harmonic distortion | <1% 1kHz | —— | |||
| System connection control contact output/input | System fault relay output | Short circuit, no voltage | |||
| Emergency mode relay output | Short circuit, no voltage | ||||
| Fire reset input | Short circuit, t≥0.5S, no voltage | ||||
| 8 channel dry contact output | Short circuit, no voltage | ||||
| 8 dry contact input | Short circuit mode | Short circuit input, no voltage | |||
| Level mode | 3.3V~24V | ||||
| Voice message | Data format | WAV | —— | ||
| Storage form | SD card | —— | |||
| Storage time | >10 years | —— | |||
| Working power | AC | AC 220-240V/50-60Hz | |||
| DC | DC 24V/30A | ||||
| Package size (L*W*H) | 550×510×215mm | ||||
| Machine size (L*W*H) | 483×420×132mm | ||||
| G.W. | 14kg | 13.3kg | |||
| N.W. | 12.05kg | 11.75kg | |||
