ZKTeco iClock880-H Large Capacity Fingerprint Time & Attendance and Access Control Terminal
Call for Price
• 50,000 templates (1: N) and 800,000 records.
• Multimedia 3.5’’ TFT screen.
• Internal Camera and Photo- ID support the user’s photo display and make T&A application more visible and reliable.
• Built-in backup battery.
• Optional integrated proximity or smart card reader.
• Built-in USB port allows for manual data transfer when network isn’t available.
• 8 user-defined function keys.
• Relay contacts for lock and alarm.
• Multi Languages Support.
• Audio-Visual indications for acceptance and rejection of valid/invalid fingers.
• SDK available for OEM customers and software devel opers.
Description
Technical Specifications |
|
| Fingerprint Capacity | 50,000 |
| Transaction Capacity | 800,000 |
| Hardware Platform | ZEM600 |
| Sensor | ZK Optical Sensor |
| Algorithm Version | ZK Finger v10.0 |
| Communication | TCP/IP |
| Standard Functions | Workcode, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, T9 input, Anti-passback, 9 digit user ID, photo-ID, Camera, Built-in Battery |
| Access Control Interface | 3rd Party Electric Lock, Door Sensor, Ext Button, Alarm, and Door Bell |
| Wiegand Signal | Input & Output |
| Optional Functions | ID/Mifare/HID, External Printer, ADMS |
| Display | 3.5 inches TFT Screen |
| Power Supply | 12V DC 3A |
| Operating Temperature | 0°C – 45°C |
| Operating Humidity | 20% – 80% |
| Dimension | 213×178.2×47.5 mm |
| Gross Weight | 1.95kg |
